PEKK NATURAL – 92 in³ (1510 cc)
High-Performance PEKK Filament — 92 in³ (1510cc) Fortus® Canister Format
PEKK is an ultra-high-performance thermoplastic selected for demanding thermal and chemical environments. This Fortus®-class PEKK is configured for the 92 in³ (1510cc) metal canister workflow, engineered around the fundamentals that drive repeatability in high-temperature production printing:
1.795 mm nominal diameter, disciplined drying, and sealed Mylar packaging.
Cross-reference intent: Stratasys® Antero™ 800NA (PEKK), Fortus Plus 92ci (355-02500). OEM identifiers are used for identification only.
Overview
NEXT 3DP PEKK is a Fortus®-class, high-temperature material designed for users who need extreme performance and are willing to pay for it. In practice, successful PEKK printing comes down to workflow control: stable feeding, stable extrusion, and moisture discipline across long builds.
- Format: 92 in³ (1510cc) metal canister
- Diameter: 1.795 mm nominal (Fortus class)
- Workflow: dried prior to packaging + sealed Mylar moisture control
- Documentation: COA / CoC + lot traceability (program dependent)
- Cross-reference: Antero™ 800NA 92ci (355-02500) identification context
Practical takeaway PEKK is unforgiving. Control dryness + dimensional stability and the printer behaves predictably.
Quick specs
Polymer family
PEKK (unfilled)
Nominal diameter
1.795 mm
Canister format
92 in³ (1510cc)
Packaging
Sealed Mylar
EEPROM sold separately (printer model dependent). If you’re not sure which EEPROM you need, contact us and we’ll match it to your system.
Specs that matter in Fortus® high-temperature printing
High-temperature polymers are moisture-sensitive and Fortus® builds are long — so the practical drivers are feed stability and moisture control: correct nominal diameter (1.795 mm), controlled ovality, disciplined drying, and packaging that stays dry until use.
Workflow control factors
- Fortus® nominal diameter: 1.795 mm
- Diameter & ovality control for stable feed
- Dried prior to packaging (moisture discipline)
- Sealed Mylar packaging to preserve dryness until use
- High-temp build discipline: consistent handling + storage
Documentation & traceability
- Certificate of Analysis (COA) (typical)
- Certificate of Conformance (CoC) (typical)
- Lot traceability for repeat builds and controlled workflows
- Additional documentation may be available (program / application dependent)
Resin specs (baseline) — Kepstan® 7002 reference
The table below summarizes baseline resin properties for Kepstan® 7002 PEKK (published reference values). Finished filament performance depends on print parameters, raster strategy, and build conditions.
| Property | Typical value | Test / notes |
|---|---|---|
| Glass transition temperature (Tg) | 162°C | ISO 11357 |
| Melting temperature (Tm) | 336°C | ISO 11357 |
| Heat deflection temperature @ 1.80 MPa | 164°C | ISO 75 |
| Tensile modulus | 3800 MPa | ISO 527 |
| Yield stress | 114 MPa | ISO 527 |
| Yield strain | 5.5% | ISO 527 |
| Nominal strain at break | 15% | ISO 527 |
| Charpy impact (unnotched) @ +23°C | 62 kJ/m² | ISO 179/1eU |
| Charpy impact (unnotched) @ −30°C | 41 kJ/m² | ISO 179/1eU |
| Charpy notched impact @ +23°C | 4.5 kJ/m² | ISO 179/1eA |
| Limiting Oxygen Index (LOI) | 38% | ISO 4589 |
| Density | 1.29 g/cm³ | ISO 1183 |
| Water absorption (reference) | 0.5% | Similar to ISO 62 |
| Humidity absorption (reference) | 0.1% | Similar to ISO 62 |
Note: These are published resin reference values for Kepstan® 7002. Printed part properties vary with orientation, raster strategy, and thermal history.
Fortus® compatibility
Designed for elevated-chamber Fortus® workflows. EEPROM selection is printer-model dependent.
| Item | Details |
|---|---|
| Compatible systems | Fortus® 360mc, 380mc, 400mc, 450mc, 900mc, F900 (configuration dependent) |
| Canister format | 92 in³ (1510cc) metal canister |
| Filament diameter | 1.795 mm nominal (Fortus class) |
| EEPROM | Sold separately (Classic vs Plus, printer-model dependent) |
| Cross-reference identifier | Stratasys® Antero™ 800NA (PEKK), Fortus Plus 92ci: 355-02500 (identification context only) |
Packaging & handling
Packaging
- Dried prior to packaging
- Sealed Mylar moisture barrier
- Shipped to preserve dryness for high-temperature builds
Storage (recommended)
- Keep sealed until use
- Reseal promptly after loading
- Store cool and dry; avoid prolonged humidity exposure
PEKK FAQ (Fortus®)
What does “92ci” mean for Fortus® material pricing?
92ci (92 cubic inches) is the standard Fortus® reference format used to compare material costs consistently. Use the cost calculator to convert part volume into cost-per-part.
Does PEKK need drying?
Yes. PEKK is moisture-sensitive. Dryness and moisture-controlled packaging reduce variability and support repeatable extrusion behavior on long builds.
Is this the same as Stratasys® Antero™ 800NA?
This product is a Fortus®-class PEKK option. The Antero™ 800NA identifier (355-02500) is provided for cross-reference / identification context only. OEM names are used for identification only.
Which EEPROM do I need?
EEPROM selection is printer-model dependent (Classic vs Plus, and system type). Contact us with your machine model and we’ll match the correct option.
How do I estimate cost per part?
Use the Fortus Material Cost Calculator to convert your part volume into cost-per-part using 92ci reference format pricing.
Trademarks: Stratasys® and Fortus® are registered trademarks of Stratasys, Inc. Antero™ is a trademark of Stratasys Ltd. Kepstan® is a trademark of Arkema. NEXT 3DP is an independent supplier. OEM names and part numbers are used for identification only.
